Domestic Sewage Treatment Plant (STP)

Compact | Modular | High-Efficiency Wastewater Treatment

The Domestic Sewage Treatment Plant (also called a Johkasou or packaged STP ) is a plug-and-play domestic sewage recycling solution designed for residential villas, farms, small communities, hotels, resorts, labor camps, and rural areas.

Using the A2O biological treatment process (Anaerobic–Anoxic–Aerobic) and advanced MBBR biofilm technology, the Johkasou efficiently removes BOD, COD, TSS, nitrogen, phosphorus and other impurities from domestic wastewater.

🔑 Key Features & Technical Benefits

• ⚡ Advanced A+A+O Process & MBBR Technology – Efficient biological wastewater treatment with nitrogen and phosphorus removal.
• 🌱 High-Performance Bio Media – Hydrophilic Polyurethane (HPU) MBBR media (>6000 m²/m³ surface area) for rapid biofilm growth, high microbial density, and stable effluent.
• 💧 Effluent Quality – Consistently meets Class 1B effluent standards: BOD ≤ 20 mg/L, COD ≤ 60 mg/L, TSS ≤ 20 mg/L, TP ≤ 3 mg/L.
• 🛠️ Plug-and-Play Packaged STP – Factory-assembled unit with integrated aeration system, blowers, and control panel.
• 🏡 Space-Saving Design – Underground installation requires minimal land compared to conventional sewage treatment plants.
• 🔧 Low Operation & Maintenance – Only sludge removal every 8–14 months; low energy consumption due to efficient aeration.
• ⏳ Durable Construction – FRP / SMC molded purification tank, corrosion-resistant, with 30+ years underground service life.

⚙️ Johkasou Treatment Process Flow

1. Oil & Sedimentation Chamber – Removes oil, grease, sand, and heavy solids.
2. Anaerobic Tank – Breaks down macromolecules, releases phosphorus, and reduces organic load.
3. Anoxic Tank – Denitrification process converts nitrates to nitrogen gas, reducing nitrogen levels.
4. Aerobic Contact Oxidation Tank – Uses bio-media and aeration for nitrification, BOD & COD reduction, and phosphorus uptake.
5. Secondary Sedimentation Tank – Settles suspended solids; treated water discharged meeting discharge standards.

📍 Applications of Johkasou STP

• Residential sewage treatment – villas, apartment complexes, gated communities.
• Commercial wastewater treatment – hotels, resorts, restaurants, malls.
• Institutional STP – schools, hospitals, offices.
• Remote & off-grid areas – rural villages, highway service stations, construction sites, worker camps.
• Industrial wastewater (low-strength) – aquaculture, food processing, small industries.

📊 Available Capacities

• Small scale: 1 – 5 m³/day (suitable for villas, small facilities).
• Medium scale: 10 – 30 m³/day (suitable for communities, resorts, labor camps).
• Large scale: 30 – 50+ m³/day (suitable for villages, commercial complexes).

Custom designs available for higher capacities.

Why Choose Johkasou?

✔ Alternative to septic tanks – provides real wastewater treatment, not just storage.

✔ Cheaper than conventional STPs – lower civil works, fabrication costs, O&M costs, and footprint.

✔ Complies with municipal & environmental discharge regulations.

✔ Fast installation - Easy to set up & commission.
